SPECTRA OWNER GUIDE
Find the commercial filter stages, AC booster, 30% Spectra-Pearson pump and MPC controls. Match the installed pump, membrane elements and electrical interfaces before choosing replacement parts.
2009–2017 Mk II MPC generation · 220V ACIdentify main power, controls and fitted equipment independently.
AC input does not identify DC controls or solenoid outputs.
Confirm the actual pump ratio and revision.
Carbon flushing uses a separate housing.
Identify actual dimensions, vessel count and end caps.
Identify installed equipment before retrofit or generator service.
Confirm a suitable supply separately from the motor and MPC board.
Mechanical references are available while power is unidentified.
MATCH THE GENERATION AND SERIAL RECORD
The manufacturer index separates Mk II MPC from 2018-current Connect. This guide uses the original Mk II manual headed “MPC 5000 from S/N 3840.” An earlier serial does not automatically prove MPC-3000; inspect the installed box and any changes.
Manufacturer generation index ↗ · Manual scope ↗The documented Farallon 2800 uses a 30% SP5 Spectra-Pearson pump. Commercial sediment filters and a separate carbon flush module serve different paths. Clark Pump and Newport feed-head parts are excluded.
Original piping schematic ↗ · Shared pump identification ↗Boat AC input, VFD three-phase motor output, MPC DC board supply and flush/diversion outputs are separate details. The shared parts guide covers later equipment; verify actual revision before using a current assembly.
AC input ↗ · DC controls ↗ · Wiring diagram ↗COMMERCIAL CARTRIDGES AND ACTUAL HOUSINGS
Seawater: strainer → inlet service module → booster → 20-micron commercial filter → 5-micron commercial filter → Pearson pump / membranes. Freshwater flushing enters through its separate carbon module.
| Stage | Part / nominal size | Location and purpose |
|---|---|---|
| First sediment | FT-FTC-20BB Nominal 10 in long × 4 in diameter | After the booster, before 5 micron. |
| Second sediment | FT-FTC-5BB Nominal 10 in long × 4 in diameter | After 20 micron, before the Pearson pump. |
| Carbon freshwater flush | FT-FTC-CCBB Nominal 10 in long × 4 in diameter | Separate domestic-water flush path; chlorine protection. |
The later shared picture names 10BC3P1 large clear housing. The original manual names 3PS20BB housing seal; the manufacturer matrix pairs the large three-piece family with 20BB3PCS wrench. Verify actual bowl, locking ring and seal with Spectra.
A 20BB seal or wrench code does not select a 20-inch cartridge. Standard 10 × 2.5-inch cartridges and black 10H seals/wrenches are different families.
Original spare list ↗The older manual uses FT-FTC-CCBB10; the current manufacturer names FT-FTC-CCBB. Confirm actual carbon housing and current package. Carbon remains a separate check when sediment housings have changed. Replace the carbon element at least every six months under the original manual; fitted Z-Ion does not establish chlorine protection.
Filter maintenance ↗ · Current carbon reference ↗Current 5-micron and carbon references specify nominal 4 × 10-inch elements. The July 2025 Connect fact sheet also specifies 4 × 10-inch 20/5 sediment elements; it is a later dimensional comparison. Confirm actual length, diameter and ends. Do not transfer Connect controls, electrical options or vessel quantities to this MPC installation.
Later filter-dimension comparison ↗
Identify the installed large three-piece family. Physical housing dimensions and nominal cartridge size are different measurements.
Open full-size source ↗ELEMENTS AND VESSEL HARDWARE ARE DIFFERENT REPAIRS
4 × 40-inch seawater membrane kit supplies one membrane and seals. The original list names FT-MB-SW4X40. Identify actual labels, dimensions and installed count before ordering. No whole-system order quantity is selected.
Original membrane reference ↗ · Current single-element kit ↗The shared drawing names FT-PV-EC4IN cap and FT-PV-ER4IN ring. Second-generation cap candidate requires actual vessel and revision confirmation with Spectra. The element, cap, ring and seals have separate scopes. Missing exact legacy listings are kept as identification codes.
Vessel parts ↗Shared and later illustrations identify components, not every original 1800/2800 arrangement. Record actual number of vessels and element labels, including changed stacks. Later Connect vessel counts are not used to set an MPC order quantity.
AC INPUT, TWO DRIVES AND SEPARATE DC CONTROLS
The Mk II installation section lists 220V AC for the 2800. A different historical fact sheet or later model does not certify a 110V conversion. Verify actual input and drive configuration with Spectra. No 24V or 48V DC main-motor option is inferred.
Model AC supply ↗Shared two-HP 220V three-phase motor receives the Pearson drive’s output. Shared 8-GPM AC booster has its own drive and feeds the commercial filters. A 110V boat input does not select 110V replacement motors.
Two-HP NEMA4 drive candidate needs actual rating, terminals, signal and programming confirmation with Spectra. A single code does not establish both complete drives.
Motor identification ↗ · Booster identification ↗Identify actual MPC board supply at Batt+ / Batt− independently of AC input. Flush valve, product-diversion valve, cooling fan and optional accessory power can have different outputs. Factory accessory outputs are limited; do not connect motors or pumps as accessories.
DC connections ↗ · Accessory outputs ↗SP5 RECOVERY RATIO AND ACTUAL REVISION
Shared identification and current manufacturer service-kit selectors assign 20% to Farallon 1800 and 30% to Farallon 2800. Select the confirmed 30% SP5 above to show this guide’s ratio-specific kit references. A changed pump needs its own service route.
Model / ratio identification ↗2,500-hour seal kit contains all pump seals; 10,000-hour internal kit contains all internal components. Confirm actual revision, condition, supplied scope and overlap with Spectra. The kit names do not replace the installed pump’s inspection and service instructions.
Manufacturer seal-kit selector ↗ · Manufacturer internal-kit selector ↗The drawing below is explicitly labeled 30% SP5M from the March 2025 Connect manual. It helps identify components after confirming actual SP5 revision. It does not certify every later internal part, wiring assembly or control kit for the 2009–2017 MPC system.
ACTUAL CONTROLLER AND CHIP GOVERN THE PROBE
The Mk II spare list names SP4. Earlier SP1/SP2/SP3 hardware and controller replacements require an actual board/chip check. A standalone board is not a complete system conversion.
Identify the installed controller and chip.
SP4 alone is not compatible. Confirm an approved complete conversion, Pearson and booster drive interfaces, actual DC supply, wiring and programming with Spectra. This guide does not automatically recommend a generic Newport conversion kit.
A40 board plus SP4 is the current listed route. Confirm installed interfaces and programming.
SP4 requires EL-MPC-SPCBA daughter board, or A40 plus SP4. No exact daughter-board listing is invented; confirm availability. The probe alone is insufficient.
SP4 is listed as compatible. Match actual connector, 15-foot reach and calibration. The shorter SP4N is a separate conditional candidate.
After installation, use the procedure for the installed controller and compare its salinity reading with a calibrated independent meter. The original MPC manual uses Salinity Cal through the display. A product-flow reading does not certify water quality.
Original MPC salinity calibration ↗ · Current chip / probe compatibility table ↗OPTIONAL RETROFIT AND FITTED-GENERATOR SERVICE
Current automated Z-Ion candidate requires confirmed MPC controls, suitable trigger/connector, plumbing and an approved 12/24V DC accessory supply. Do not connect it directly to AC or 48V. Confirm the full current package with Spectra. Board voltage alone does not establish an approved accessory connection.
Historical Z-ION-FAR and ZION-FL are not assumed aliases. Plug assembly candidate depends on the actual harness and whether it is already supplied.
Manufacturer system selector ↗Combined replacement bowl and rod serves an installed matching generator. Do not automatically add a separate rod. Loose bowl/rod candidates require actual connector and threaded-base confirmation; they do not supply a complete retrofit or controller.
Current combined service assembly ↗Z-Ion can change approved storage practice after a correctly commissioned installation. Follow its actual instructions and confirm chlorine protection. Z-Ion and SC-1 do not prevent freezing; use the current fitted-system winterizing procedure.
Original winterizing ↗FUNCTION, PRESSURE RATING AND ACTUAL CONNECTION
Shared drawings name 12V freshwater-flush solenoid without body and a separate 220V product-diversion valve. Match actual coil output, body, adapter and function with Spectra. Main motor or MPC supply does not establish either coil’s output.
Flush / sensors ↗ · Diversion manifold ↗150-PSI transducer needs actual sensing location and range confirmation. Shared EL-SSR-IFM4GPM has no exact listing here; SP5 flow assembly candidate requires range, connector and calibration review. SP4 measures salinity separately.
The manual’s product-tube inch/mm conversion is inconsistent. Match actual marked outside diameter and fittings. Low-pressure product tubing is never a high-pressure replacement. The original PL-HS-1/2HP hose and shared high-pressure tube are different codes; confirm assembly and pressure rating.
Confirm actual O-ring/UNF versus tapered thread geometry. Similar diameter alone does not establish a connection.
Product plumbing ↗ · High-pressure hose service ↗LABELED MANUFACTURER DRAWINGS
Original MPC pages and shared later references are labeled separately. Open each source for full-size callouts. Confirm actual revision before ordering a pictured component.
Showing all assembly drawings.
Follow strainer, inlet service module, booster, 20/5 sediment pair and separate carbon flush path. The original source contains inconsistent inch/mm and pressure conversions; use actual component markings and approved instructions.
Open full-size source ↗
The inlet service valve is between strainer and booster. Booster and suction hose remain below the waterline for priming.
Open full-size source ↗
Booster feeds 20 micron, then 5 micron, then the high-pressure module. Mount bowls vertically with service clearance.
Open full-size source ↗
Confirm domestic supply, regulator and actual flush volume. AC motor input does not determine flush-solenoid output.
Open full-size source ↗
Confirm installed SP5 ratio and module revision. Later drawings do not prove every original membrane count or assembly.
Open full-size source ↗
Shared component reference identifies 1800 as 20% and 2800 as 30%. Two-HP three-phase motor, manifold, valve and mounts are separate items; confirm actual revision.
Open full-size source ↗
Fan and internal controls are distinct from AC main power. This later component picture requires actual wiring and supply confirmation.
Open full-size source ↗
SP4, 150-PSI transducer and IFM4GPM flow meter have separate functions. The flush valve is separate from the 220V diversion assembly.
Open full-size source ↗
Legacy drawing labels EC4IN and ER4IN. A catalog second-generation end cap needs actual vessel and revision confirmation.
Open full-size source ↗
Product tubing is different from high-pressure tubing or hose. Measure outside diameter and identify fittings before substitution.
Open full-size source ↗
Later shared picture shows the 10-inch commercial carbon module. Identify actual bowl, seal and wrench family.
Open full-size source ↗
Large-diameter 10-inch cartridges are different from standard 2.5-inch elements and 20-inch commercial elements.
Open full-size source ↗
Shared reference names 8 GPM, 220V / 60Hz. Confirm actual speed-controller output and pump nameplate, including on 110V-input 1800 systems.
Open full-size source ↗
Seawater intake and chemical-service hose share this service valve. Confirm port routing and return to run position after service.
Open full-size source ↗
Brine discharge and service recirculation are different paths. Match actual ports, thread forms and hose fittings.
Open full-size source ↗
Match six-inch screen, seal and actual check-valve construction. Similar spring/no-spring codes are not universal aliases.
Open full-size source ↗
Identify actual DC supply at the MPC board. Main motor AC power and accessory/coil output remain independent checks.
Open full-size source ↗
Separate booster and Pearson drives are shown with AC input and three-phase outputs. Wiring changes require the actual diagram and factory programming; this image is rotated upright for reading.
Open full-size source ↗
Manual mode overrides automatic safeguards. Do not use it to bypass unresolved alarms or treat a flow reading as a water-quality test.
Open full-size source ↗
Original manual specifies 5W-30 synthetic and 5,000 hours or annually, whichever first. Changed crankcases need their own current instructions; later Connect intervals are not transferred.
Open full-size source ↗
Later Connect manual reference, explicitly labeled 30%. Identify actual SP5 revision before applying internal components; it does not certify a controls conversion. Rotated upright for reading.
Open full-size source ↗FOLLOW THE INSTALLED-SYSTEM PROCEDURE
Inspect the strainer and replace loaded sediment filters with new elements under the Mk II maintenance section. Replace the carbon element at least every six months. The older generic appendix’s wash/reuse wording and extra filter stages are not transferred to this guide.
Model filter maintenance ↗The original counterclockwise CAT crankcase section specifies 5W-30 synthetic oil, changed at 5,000 hours or annually, whichever comes first. Check level and contamination. Match an altered crankcase or pump to its own current instructions. The later Connect 300-hour interval is not transferred.
Original oil-change kit code KIT-SPP5-OP has no exact catalog listing here; confirm its current availability with Spectra.
Original oil procedure ↗The original five-day Auto Store requires uninterrupted AC power, DC controls and pressurized domestic water. Confirm actual flush-volume calibration and installation. A power interruption or changed controller can invalidate the automatic-storage setup.
Flush calibration ↗ · Auto Store ↗SC-1 is storage compound; SC-2 and SC-3 are separate conditional cleaners. Diagnose poor flow/quality before cleaning. Never mix SC-2 and SC-3; use nonchlorinated water and the approved sequence.
The original manual gives inconsistent gallon/liter conversions for retained volume. No numeric chemical dose or automatic cleaning volume is provided here. Confirm actual installed volume and current Spectra procedure. Open the pressure-relief valve only under the prescribed depressurized service procedure and purge correctly before pressurizing.
Storage ↗ · Cleaning ↗ · Procedure ↗Current Cruise Kit D lists three commercial 20-micron, three commercial 5-micron, one commercial carbon element and two SC-1 packs. The older manual’s abbreviated kit description omits carbon. Confirm present package contents; spare-stock quantities are separate from fitted counts.
Current manufacturer kit contents ↗ANSWERS THAT CHANGE THE PART CHOICE
No. This manual names 10-inch commercial elements and a 3PS20BB seal. Match the actual bowl, ring, element dimensions and wrench family.
No. These documented Farallon models use SP5 Spectra-Pearson pumps: 1800 is 20%, 2800 is 30%. Confirm changed pumps separately.
The drives separate boat input from three-phase motor output. Check each nameplate and drive; do not choose replacements from boat input alone.
No. Confirm an approved 12/24V DC accessory supply, wiring and current retrofit package with Spectra. AC and 48V must not power Z-Ion directly.
Count the actual fitted elements and read their labels. One kit serves one confirmed 4 × 40-inch element. Later Connect vessel counts are not used as this MPC system’s order quantity.
No. The Farallon Pearson and booster drive interfaces, actual supply, wiring and programming need factory review. SP4 alone and a standalone A40 board are not complete MPC-3000 conversions.
MODEL-SCOPED REFERENCES WITH THEIR REQUIREMENTS
Named model and current manufacturer references appear first. Changed-hardware candidates remain separate and conditional. A selection does not verify a retrofit, live stock or price.
57 references.
No matching references. Clear search or check your selections above.
Mk II MPC · 220V AC · Named in Mk II MPC manual
Confirm with Spectra before ordering. Mk II MPC chemical-service reference. Older KIT-CHEM code and current catalog code require package confirmation. SC-1 is storage compound; SC-2 and SC-3 are separate conditional cleaners and must never be mixed. Confirm actual retained volume, current Spectra procedure and chemical compatibility. Manual gallon/liter conversions conflict; no numeric dose is selected here. SC-1 and Z-Ion do not prevent freezing.
Mk II MPC chemical-service reference. Older KIT-CHEM code and current catalog code require package confirmation. SC-1 is storage compound; SC-2 and SC-3 are separate conditional cleaners and must never be mixed. Confirm actual retained volume, current Spectra procedure and chemical compatibility. Manual gallon/liter conversions conflict; no numeric dose is selected here. SC-1 and Z-Ion do not prevent freezing.
Mk II MPC · 220V AC · Named in Mk II MPC manual
Confirm with Spectra before ordering. Mk II MPC chemical-service reference. Older KIT-CHEM code and current catalog code require package confirmation. SC-1 is storage compound; SC-2 and SC-3 are separate conditional cleaners and must never be mixed. Confirm actual retained volume, current Spectra procedure and chemical compatibility. Manual gallon/liter conversions conflict; no numeric dose is selected here. SC-1 and Z-Ion do not prevent freezing.
Mk II MPC chemical-service reference. Older KIT-CHEM code and current catalog code require package confirmation. SC-1 is storage compound; SC-2 and SC-3 are separate conditional cleaners and must never be mixed. Confirm actual retained volume, current Spectra procedure and chemical compatibility. Manual gallon/liter conversions conflict; no numeric dose is selected here. SC-1 and Z-Ion do not prevent freezing.
Mk II MPC · 220V AC · Named in Mk II MPC manual
Confirm with Spectra before ordering. Mk II MPC chemical-service reference. Older KIT-CHEM code and current catalog code require package confirmation. SC-1 is storage compound; SC-2 and SC-3 are separate conditional cleaners and must never be mixed. Confirm actual retained volume, current Spectra procedure and chemical compatibility. Manual gallon/liter conversions conflict; no numeric dose is selected here. SC-1 and Z-Ion do not prevent freezing.
Mk II MPC chemical-service reference. Older KIT-CHEM code and current catalog code require package confirmation. SC-1 is storage compound; SC-2 and SC-3 are separate conditional cleaners and must never be mixed. Confirm actual retained volume, current Spectra procedure and chemical compatibility. Manual gallon/liter conversions conflict; no numeric dose is selected here. SC-1 and Z-Ion do not prevent freezing.
Mk II MPC · 220V AC · Named in Mk II MPC manual
Confirm with Spectra before ordering. Mk II spare list names SP4. Actual MPC-5000 chip governs the replacement path: B-series/A31 require A40 plus SP4; A34/A35 require the daughter interface or A40; A36/A37/A39/A40 accept SP4. Match connector, 15-foot reach and calibration with Spectra. MPC-3000 cannot use SP4 alone.
Mk II spare list names SP4. Actual MPC-5000 chip governs the replacement path: B-series/A31 require A40 plus SP4; A34/A35 require the daughter interface or A40; A36/A37/A39/A40 accept SP4. Match connector, 15-foot reach and calibration with Spectra. MPC-3000 cannot use SP4 alone.
Existing fitment requirements
Mk II MPC · 220V AC · Named in Mk II MPC manual
Confirm with Spectra before ordering. 6" Strainer Screen (Large) is identified in the Mk II MPC suggested spares list. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
6" Strainer Screen (Large) is identified in the Mk II MPC suggested spares list. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
Mk II MPC · 220V AC · Named in Mk II MPC manual
Confirm with Spectra before ordering. Hand Held Meter Kit is identified in the Mk II MPC suggested spares list. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
Hand Held Meter Kit is identified in the Mk II MPC suggested spares list. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
Mk II MPC · 220V AC · Named in Mk II MPC manual
Confirm with Spectra before ordering. Large three-piece Big Blue housing family: match actual bowl, locking ring, seal section and wrench engagement. The Mk II manual names SO-FHS-3PS20BB while its cartridges are 10-inch commercial elements. The 20BB seal/wrench name does not establish a 20-inch cartridge. Later drawings show FT-FTH-10BC3P1; confirm this housing revision with Spectra. Standard small-diameter and black 10H hardware are different families.
Large three-piece Big Blue housing family: match actual bowl, locking ring, seal section and wrench engagement. The Mk II manual names SO-FHS-3PS20BB while its cartridges are 10-inch commercial elements. The 20BB seal/wrench name does not establish a 20-inch cartridge. Later drawings show FT-FTH-10BC3P1; confirm this housing revision with Spectra. Standard small-diameter and black 10H hardware are different families.
Mk II MPC · 220V AC · Named in Mk II MPC manual
Confirm with Spectra before ordering. 6" Strainer Seal (Big) is identified in the Mk II MPC suggested spares list. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
6" Strainer Seal (Big) is identified in the Mk II MPC suggested spares list. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
Mk II MPC · 220V AC · commercial 10-inch sediment elements · Current manufacturer reference
Confirm with Spectra before ordering. First sediment stage after the booster and before the 5-micron element. Manufacturer nominal dimensions: 10 inches long × 4 inches diameter. The 2025 Farallon Connect fact sheet supplies a later dimensional comparison for the 20-micron family, not MPC power or installed membrane count. Measure actual element, ends and bowl; do not choose 20-inch cartridges from the seal code.
First sediment stage after the booster and before the 5-micron element. Manufacturer nominal dimensions: 10 inches long × 4 inches diameter. The 2025 Farallon Connect fact sheet supplies a later dimensional comparison for the 20-micron family, not MPC power or installed membrane count. Measure actual element, ends and bowl; do not choose 20-inch cartridges from the seal code.
Mk II MPC · 220V AC · commercial 10-inch sediment elements · Current manufacturer reference
Confirm with Spectra before ordering. Second sediment stage, after 20 micron and before the Pearson pump. Manufacturer nominal dimensions: 10 inches long × 4 inches diameter. The 2025 Farallon Connect fact sheet supplies a later dimensional comparison for the 20-micron family, not MPC power or installed membrane count. Measure actual element, ends and bowl; do not choose 20-inch cartridges from the seal code.
Second sediment stage, after 20 micron and before the Pearson pump. Manufacturer nominal dimensions: 10 inches long × 4 inches diameter. The 2025 Farallon Connect fact sheet supplies a later dimensional comparison for the 20-micron family, not MPC power or installed membrane count. Measure actual element, ends and bowl; do not choose 20-inch cartridges from the seal code.
Mk II MPC · 220V AC · Current manufacturer reference
Confirm with Spectra before ordering. Separate freshwater-flush carbon stage for chlorine protection. The old manual names FT-FTC-CCBB10; current manufacturer code is FT-FTC-CCBB. Confirm the current code and fitted housing rather than assuming a suffix alias. Manufacturer nominal dimensions: 10 inches long × 4 inches diameter. The 2025 Farallon Connect fact sheet supplies a later dimensional comparison for the 20-micron family, not MPC power or installed membrane count. Measure actual element, ends and bowl; do not choose 20-inch cartridges from the seal code.
Separate freshwater-flush carbon stage for chlorine protection. The old manual names FT-FTC-CCBB10; current manufacturer code is FT-FTC-CCBB. Confirm the current code and fitted housing rather than assuming a suffix alias. Manufacturer nominal dimensions: 10 inches long × 4 inches diameter. The 2025 Farallon Connect fact sheet supplies a later dimensional comparison for the 20-micron family, not MPC power or installed membrane count. Measure actual element, ends and bowl; do not choose 20-inch cartridges from the seal code.
Mk II MPC · 220V AC · confirmed 4 × 40-inch element · Current manufacturer reference
Confirm with Spectra before ordering. Current manufacturer kit supplies one 4 × 40-inch seawater membrane and seals. The Mk II MPC spare list names historical bare element FT-MB-SW4X40. Identify actual element dimensions, labels, number of vessels, end caps and seal revision with Spectra. This is not a complete vessel or an automatic whole-system order quantity. Later Connect vessel counts are not transferred to this Mk II MPC.
Current manufacturer kit supplies one 4 × 40-inch seawater membrane and seals. The Mk II MPC spare list names historical bare element FT-MB-SW4X40. Identify actual element dimensions, labels, number of vessels, end caps and seal revision with Spectra. This is not a complete vessel or an automatic whole-system order quantity. Later Connect vessel counts are not transferred to this Mk II MPC.
Mk II MPC · 220V AC · installed Z-Ion generator · Current manufacturer reference
Confirm with Spectra before ordering. Current SUB-ZION-ELECTB combines replacement generator bowl and rod. Do not automatically add a separate rod. This is separate from a complete system or controller. Confirm installed Z-Ion bowl, rod, connector, threaded-base revision and service contents with Spectra.
Current SUB-ZION-ELECTB combines replacement generator bowl and rod. Do not automatically add a separate rod. This is separate from a complete system or controller. Confirm installed Z-Ion bowl, rod, connector, threaded-base revision and service contents with Spectra.
Existing fitment requirements
Mk II MPC · 220V AC · Current manufacturer reference
Confirm with Spectra before ordering. Current manufacturer Cruise Kit D for Farallon 1800/2800 contains three commercial 20-micron elements, three commercial 5-micron elements, one commercial carbon element and two SC-1 packs. The older manual abbreviated its contents without the carbon element. These are spare-stock quantities, not installed cartridge counts; confirm current supplied contents and actual housing family with Spectra.
Current manufacturer Cruise Kit D for Farallon 1800/2800 contains three commercial 20-micron elements, three commercial 5-micron elements, one commercial carbon element and two SC-1 packs. The older manual abbreviated its contents without the carbon element. These are spare-stock quantities, not installed cartridge counts; confirm current supplied contents and actual housing family with Spectra.
Mk II MPC · 220V AC · confirmed 30% SP5 Pearson pump · Current manufacturer reference
Confirm with Spectra before ordering. Farallon 2800 uses the documented 30% SP5 Spectra-Pearson pump. Current manufacturer 10,000-hour kit contains all internal pump components. Confirm actual SP5 revision, recovery ratio, condition, current pack contents and overlap before ordering. The service-kit name is not a substitute for inspection or the installed pump instructions. Clark Pump and 50% LB4000 kits are excluded.
Farallon 2800 uses the documented 30% SP5 Spectra-Pearson pump. Current manufacturer 10,000-hour kit contains all internal pump components. Confirm actual SP5 revision, recovery ratio, condition, current pack contents and overlap before ordering. The service-kit name is not a substitute for inspection or the installed pump instructions. Clark Pump and 50% LB4000 kits are excluded.
Mk II MPC · 220V AC · confirmed 30% SP5 Pearson pump · Current manufacturer reference
Confirm with Spectra before ordering. Farallon 2800 uses the documented 30% SP5 Spectra-Pearson pump. Current manufacturer 2,500-hour kit contains all pump seals. Confirm actual SP5 revision, recovery ratio, condition, current pack contents and overlap before ordering. The service-kit name is not a substitute for inspection or the installed pump instructions. Clark Pump and 50% LB4000 kits are excluded.
Farallon 2800 uses the documented 30% SP5 Spectra-Pearson pump. Current manufacturer 2,500-hour kit contains all pump seals. Confirm actual SP5 revision, recovery ratio, condition, current pack contents and overlap before ordering. The service-kit name is not a substitute for inspection or the installed pump instructions. Clark Pump and 50% LB4000 kits are excluded.
Mk II MPC · 220V AC · approved 12/24V DC accessory supply and retrofit review · Current manufacturer reference
Confirm with Spectra before ordering. Automated MPC Z-Ion retrofit candidate only after confirming no generator is fitted and an approved 12/24V DC accessory supply is available. Do not connect Z-Ion directly to AC or 48V. Confirm installed controls, trigger/harness, plumbing, connector and complete current package with Spectra. Current manufacturer control-type route is ZION-AUTO.
Automated MPC Z-Ion retrofit candidate only after confirming no generator is fitted and an approved 12/24V DC accessory supply is available. Do not connect Z-Ion directly to AC or 48V. Confirm installed controls, trigger/harness, plumbing, connector and complete current package with Spectra. Current manufacturer control-type route is ZION-AUTO.
Existing fitment requirements
Mk II MPC · 220V AC · Shared component identification
Confirm with Spectra before ordering. Shared Farallon reference names a 150-PSI transducer. Confirm actual sensing location, range, signal, connector and MPC calibration with Spectra. It is separate from the salinity probe and does not certify a membrane high-pressure sensor by model name alone.
Shared Farallon reference names a 150-PSI transducer. Confirm actual sensing location, range, signal, connector and MPC calibration with Spectra. It is separate from the salinity probe and does not certify a membrane high-pressure sensor by model name alone.
Mk II MPC · 220V AC · Shared component identification
Confirm with Spectra before ordering. Shared drawing names a 12V Spartan freshwater-flush solenoid without valve body. Match actual body/interface, flush function, output voltage, connector and supplied scope with Spectra. AC motor input and DC board supply do not determine the flush coil. The 220V product-diversion valve is a different component.
Shared drawing names a 12V Spartan freshwater-flush solenoid without valve body. Match actual body/interface, flush function, output voltage, connector and supplied scope with Spectra. AC motor input and DC board supply do not determine the flush coil. The 220V product-diversion valve is a different component.
Existing fitment requirements
Mk II MPC · 220V AC · Shared component identification
Confirm with Spectra before ordering. High Pressure Housing Bracket Duplex is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
High Pressure Housing Bracket Duplex is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
Mk II MPC · 220V AC · Shared component identification
Confirm with Spectra before ordering. Large three-piece Big Blue housing family: match actual bowl, locking ring, seal section and wrench engagement. The Mk II manual names SO-FHS-3PS20BB while its cartridges are 10-inch commercial elements. The 20BB seal/wrench name does not establish a 20-inch cartridge. Later drawings show FT-FTH-10BC3P1; confirm this housing revision with Spectra. Standard small-diameter and black 10H hardware are different families.
Large three-piece Big Blue housing family: match actual bowl, locking ring, seal section and wrench engagement. The Mk II manual names SO-FHS-3PS20BB while its cartridges are 10-inch commercial elements. The 20BB seal/wrench name does not establish a 20-inch cartridge. Later drawings show FT-FTH-10BC3P1; confirm this housing revision with Spectra. Standard small-diameter and black 10H hardware are different families.
Mk II MPC · 220V AC · Shared component identification
Confirm with Spectra before ordering. 6" Strainer (Large) is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
6" Strainer (Large) is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
Mk II MPC · 220V AC · Shared component identification
Confirm with Spectra before ordering. 24V cooling-fan reference from the shared AC control-box drawing. Match actual voltage, size, connector, air flow and supply with Spectra. Main motor AC input does not determine this DC accessory voltage.
24V cooling-fan reference from the shared AC control-box drawing. Match actual voltage, size, connector, air flow and supply with Spectra. Main motor AC input does not determine this DC accessory voltage.
Mk II MPC · 220V AC · Shared component identification
Confirm with Spectra before ordering. 3/4" Fpt X 3/4 Hose Barb St. Nylon is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
3/4" Fpt X 3/4 Hose Barb St. Nylon is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
Mk II MPC · 220V AC · Shared component identification
Confirm with Spectra before ordering. 1/2" Npt-Fpt Flow Reg 1.5G 20-80Psi is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
1/2" Npt-Fpt Flow Reg 1.5G 20-80Psi is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
Mk II MPC · 220V AC · Shared component identification
Confirm with Spectra before ordering. 1/2" Tube X 1/2"Hb Adaptor is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
1/2" Tube X 1/2"Hb Adaptor is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
Mk II MPC · 220V AC · Shared component identification
Confirm with Spectra before ordering. 3/4" Npt X 3/4" Hose Barb Ell Nylon is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
3/4" Npt X 3/4" Hose Barb Ell Nylon is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
Mk II MPC · 220V AC · Shared component identification
Confirm with Spectra before ordering. 3/4" Npt X 5/8" Hose Barb Ell Nylon is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
3/4" Npt X 5/8" Hose Barb Ell Nylon is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
Mk II MPC · 220V AC · Shared component identification
Confirm with Spectra before ordering. 3/4" Npt X 5/8" Hose Barb St. Nylon is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
3/4" Npt X 5/8" Hose Barb St. Nylon is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
Mk II MPC · 220V AC · Shared component identification
Confirm with Spectra before ordering. Pl-Hp-3/8 is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
Pl-Hp-3/8 is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
Mk II MPC · 220V AC · Shared component identification
Confirm with Spectra before ordering. 3/4"Mpt X 3/4" Fpt Elbow Fitt. Nylon is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
3/4"Mpt X 3/4" Fpt Elbow Fitt. Nylon is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
Mk II MPC · 220V AC · Shared component identification
Confirm with Spectra before ordering. Pl-Mte-3/4X5/8P is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
Pl-Mte-3/4X5/8P is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
Mk II MPC · 220V AC · Shared component identification
Confirm with Spectra before ordering. 3/8"Npt X 3/8" Tube St Jg. is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
3/8"Npt X 3/8" Tube St Jg. is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
Mk II MPC · 220V AC · Shared component identification
Confirm with Spectra before ordering. Shared drawing labels this high-pressure tube. Mk II maintenance text separately names PL-HS-1/2HP hose; tube and hose codes are not assumed interchangeable. Confirm pressure rating, connection/thread form, material and assembly with Spectra. Diameter alone does not establish fit, and low-pressure product tubing must never replace the high-pressure path.
Shared drawing labels this high-pressure tube. Mk II maintenance text separately names PL-HS-1/2HP hose; tube and hose codes are not assumed interchangeable. Confirm pressure rating, connection/thread form, material and assembly with Spectra. Diameter alone does not establish fit, and low-pressure product tubing must never replace the high-pressure path.
Mk II MPC · 220V AC · Shared component identification
Confirm with Spectra before ordering. Low-pressure product-water tubing from the shared vessel drawing. Match actual outside diameter, material, routing and fittings with Spectra. Mk II text has an inconsistent inch/mm conversion; use actual markings and fittings. Never use this tubing on the high-pressure Pearson or membrane-feed path.
Low-pressure product-water tubing from the shared vessel drawing. Match actual outside diameter, material, routing and fittings with Spectra. Mk II text has an inconsistent inch/mm conversion; use actual markings and fittings. Never use this tubing on the high-pressure Pearson or membrane-feed path.
Mk II MPC · 220V AC · Shared component identification
Confirm with Spectra before ordering. 3/4" Npt Close Nipple Nylon is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
3/4" Npt Close Nipple Nylon is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
Mk II MPC · 220V AC · Shared component identification
Confirm with Spectra before ordering. 3/4"Npt X 1/2"Npt Close Nipple Nyl is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
3/4"Npt X 1/2"Npt Close Nipple Nyl is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
Mk II MPC · 220V AC · Shared component identification
Confirm with Spectra before ordering. 1/2"Npt X 1/2" Tube Swivel Fitt Ell is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
1/2"Npt X 1/2" Tube Swivel Fitt Ell is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
Mk II MPC · 220V AC · Shared component identification
Confirm with Spectra before ordering. 3/8"Npt X 1/2"Tube Swivel Elbow Pp is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
3/8"Npt X 1/2"Tube Swivel Elbow Pp is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
Mk II MPC · 220V AC · Shared component identification
Confirm with Spectra before ordering. 3/8"Npt X 3/8"Tube Swivel Elbow Pp is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
3/8"Npt X 3/8"Tube Swivel Elbow Pp is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
Mk II MPC · 220V AC · Shared component identification
Confirm with Spectra before ordering. 3/4"Npt X 3/4"Fpt 1-Way Pvc Valve is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
3/4"Npt X 3/4"Fpt 1-Way Pvc Valve is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
Mk II MPC · 220V AC · Shared component identification
Confirm with Spectra before ordering. 3/4" 3-Way Valve is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
3/4" 3-Way Valve is identified in the shared Farallon component reference. Match the actual location, ports, dimensions, rating, connector and revision with Spectra. The shared post-2014 drawing does not prove every assembly fits an earlier Mk II MPC. Drawing quantities do not establish supplied pack contents.
Mk II MPC · 220V AC · Shared component identification
Confirm with Spectra before ordering. Shared Farallon booster is 8 GPM, 220V / 60Hz AC, before the 20/5 commercial filters. Identify actual pump, speed-controller output, frequency, mounting and hose ports with Spectra. A 110V-input 1800 does not prove a 110V booster. This is separate from the Pearson high-pressure pump and Newport Laing boosters.
Shared Farallon booster is 8 GPM, 220V / 60Hz AC, before the 20/5 commercial filters. Identify actual pump, speed-controller output, frequency, mounting and hose ports with Spectra. A 110V-input 1800 does not prove a 110V booster. This is separate from the Pearson high-pressure pump and Newport Laing boosters.
Mk II MPC · 220V AC · Shared component identification
Confirm with Spectra before ordering. Shared Farallon drawing names a two-HP 220V AC three-phase, 1750-RPM motor. It receives VFD output; boat input is not a direct single-phase motor connection. Confirm installed shaft/frame, coupling, nameplate, frequency and drive programming with Spectra. A 110V-input 1800 may still have 220V motor output.
Shared Farallon drawing names a two-HP 220V AC three-phase, 1750-RPM motor. It receives VFD output; boat input is not a direct single-phase motor connection. Confirm installed shaft/frame, coupling, nameplate, frequency and drive programming with Spectra. A 110V-input 1800 may still have 220V motor output.
Confirm these specific links with Spectra before ordering. The source does not prove direct interchangeability, exact current revision or complete conversion contents.
Mk II MPC · 220V AC · approved 12/24V DC accessory supply and retrofit review · Installed-hardware review
Confirm with Spectra before ordering. Automated MPC Z-Ion retrofit candidate only after confirming no generator is fitted and an approved 12/24V DC accessory supply is available. Do not connect Z-Ion directly to AC or 48V. Confirm installed controls, trigger/harness, plumbing, connector and complete current package with Spectra. This historical Farallon or plug code is not assumed a universal alias; confirm exact scope and whether an adapter is included. Pre-Mk II-Z guidance requires actual harness identification, not age alone.
Automated MPC Z-Ion retrofit candidate only after confirming no generator is fitted and an approved 12/24V DC accessory supply is available. Do not connect Z-Ion directly to AC or 48V. Confirm installed controls, trigger/harness, plumbing, connector and complete current package with Spectra. This historical Farallon or plug code is not assumed a universal alias; confirm exact scope and whether an adapter is included. Pre-Mk II-Z guidance requires actual harness identification, not age alone.
Existing fitment requirements
Mk II MPC · 220V AC · Installed-hardware review
Confirm with Spectra before ordering. 25-foot approved MPC remote-cable candidate. Confirm actual routing, reach and connector with Spectra. Cable length is a separate selection and does not certify an ordinary network cable as a replacement.
25-foot approved MPC remote-cable candidate. Confirm actual routing, reach and connector with Spectra. Cable length is a separate selection and does not certify an ordinary network cable as a replacement.
Mk II MPC · 220V AC · Installed-hardware review
Confirm with Spectra before ordering. A40 MPC-5000 board candidate. B-series/A31 require board plus SP4; A34/A35 can use the daughter interface or A40 route. Confirm Pearson/boost-drive interface, wiring, output and programming with Spectra. A standalone board is not a complete MPC-3000 conversion or Connect controller.
A40 MPC-5000 board candidate. B-series/A31 require board plus SP4; A34/A35 can use the daughter interface or A40 route. Confirm Pearson/boost-drive interface, wiring, output and programming with Spectra. A standalone board is not a complete MPC-3000 conversion or Connect controller.
Existing fitment requirements
Mk II MPC · 220V AC · Installed-hardware review
Confirm with Spectra before ordering. MPC-5000 remote LCD display reference. Match installed controller, connectors and approved cable with Spectra. The optional VFD diagnostic display and later Connect touchscreen are separate devices.
MPC-5000 remote LCD display reference. Match installed controller, connectors and approved cable with Spectra. The optional VFD diagnostic display and later Connect touchscreen are separate devices.
Mk II MPC · 220V AC · Installed-hardware review
Confirm with Spectra before ordering. Short three-foot SP4N candidate. Current chip table names SP4 and does not establish every N-suffix interface as equivalent. Confirm connector, reach and required board/interface with Spectra.
Short three-foot SP4N candidate. Current chip table names SP4 and does not establish every N-suffix interface as equivalent. Confirm connector, reach and required board/interface with Spectra.
Existing fitment requirements
Mk II MPC · 220V AC · Installed-hardware review
Confirm with Spectra before ordering. Two-HP NEMA4 speed-controller candidate with 110/230V single-phase input. Match the actual Pearson or booster drive, input/output, motor rating, wiring terminals, control signal and factory programming with Spectra. Two drives are shown in the Mk II wiring diagram; this code does not automatically replace both or certify 110V support on a 2800.
Two-HP NEMA4 speed-controller candidate with 110/230V single-phase input. Match the actual Pearson or booster drive, input/output, motor rating, wiring terminals, control signal and factory programming with Spectra. Two drives are shown in the Mk II wiring diagram; this code does not automatically replace both or certify 110V support on a 2800.
Mk II MPC · 220V AC · Installed-hardware review
Confirm with Spectra before ordering. SP5 flow-sensor assembly candidate. Shared drawing names EL-SSR-IFM4GPM, which has no exact listing here. Match actual range, pulse signal, connector, plumbing and MPC calibration with Spectra; do not substitute a low-flow meter or assume every fitting is supplied.
SP5 flow-sensor assembly candidate. Shared drawing names EL-SSR-IFM4GPM, which has no exact listing here. Match actual range, pulse signal, connector, plumbing and MPC calibration with Spectra; do not substitute a low-flow meter or assume every fitting is supplied.
Mk II MPC · 220V AC · Installed-hardware review
Confirm with Spectra before ordering. Large three-piece Big Blue housing family: match actual bowl, locking ring, seal section and wrench engagement. The Mk II manual names SO-FHS-3PS20BB while its cartridges are 10-inch commercial elements. The 20BB seal/wrench name does not establish a 20-inch cartridge. Later drawings show FT-FTH-10BC3P1; confirm this housing revision with Spectra. Standard small-diameter and black 10H hardware are different families.
Large three-piece Big Blue housing family: match actual bowl, locking ring, seal section and wrench engagement. The Mk II manual names SO-FHS-3PS20BB while its cartridges are 10-inch commercial elements. The 20BB seal/wrench name does not establish a 20-inch cartridge. Later drawings show FT-FTH-10BC3P1; confirm this housing revision with Spectra. Standard small-diameter and black 10H hardware are different families.
Mk II MPC · 220V AC · confirmed 4 × 40-inch element · Installed-hardware review
Confirm with Spectra before ordering. Shared four-inch vessel drawing labels FT-PV-EC4IN end cap and FT-PV-ER4IN retaining ring. This listing names a second-generation cap; its suffix does not prove direct replacement for the legacy cap. Match actual vessel, retention hardware, ports, seals and revision with Spectra. No exact catalog link is invented for the legacy ring or cap.
Shared four-inch vessel drawing labels FT-PV-EC4IN end cap and FT-PV-ER4IN retaining ring. This listing names a second-generation cap; its suffix does not prove direct replacement for the legacy cap. Match actual vessel, retention hardware, ports, seals and revision with Spectra. No exact catalog link is invented for the legacy ring or cap.
Mk II MPC · 220V AC · installed Z-Ion generator · Installed-hardware review
Confirm with Spectra before ordering. Conditional loose bowl without rod reference; the current combined assembly does not prove this loose code fits every generator. Confirm installed Z-Ion bowl, rod, connector, threaded-base revision and service contents with Spectra.
Conditional loose bowl without rod reference; the current combined assembly does not prove this loose code fits every generator. Confirm installed Z-Ion bowl, rod, connector, threaded-base revision and service contents with Spectra.
Existing fitment requirements
Mk II MPC · 220V AC · approved 12/24V DC accessory supply and retrofit review · Installed-hardware review
Confirm with Spectra before ordering. Automated MPC Z-Ion retrofit candidate only after confirming no generator is fitted and an approved 12/24V DC accessory supply is available. Do not connect Z-Ion directly to AC or 48V. Confirm installed controls, trigger/harness, plumbing, connector and complete current package with Spectra. This historical Farallon or plug code is not assumed a universal alias; confirm exact scope and whether an adapter is included. Pre-Mk II-Z guidance requires actual harness identification, not age alone.
Automated MPC Z-Ion retrofit candidate only after confirming no generator is fitted and an approved 12/24V DC accessory supply is available. Do not connect Z-Ion directly to AC or 48V. Confirm installed controls, trigger/harness, plumbing, connector and complete current package with Spectra. This historical Farallon or plug code is not assumed a universal alias; confirm exact scope and whether an adapter is included. Pre-Mk II-Z guidance requires actual harness identification, not age alone.
Existing fitment requirements
Mk II MPC · 220V AC · installed Z-Ion generator · Installed-hardware review
Confirm with Spectra before ordering. Conditional loose rod with threaded fitting reference; the current combined assembly does not prove this loose code fits every generator. Confirm installed Z-Ion bowl, rod, connector, threaded-base revision and service contents with Spectra.
Conditional loose rod with threaded fitting reference; the current combined assembly does not prove this loose code fits every generator. Confirm installed Z-Ion bowl, rod, connector, threaded-base revision and service contents with Spectra.
Existing fitment requirements
Mk II MPC · 220V AC · approved 12/24V DC accessory supply and retrofit review · Installed-hardware review
Confirm with Spectra before ordering. Automated MPC Z-Ion retrofit candidate only after confirming no generator is fitted and an approved 12/24V DC accessory supply is available. Do not connect Z-Ion directly to AC or 48V. Confirm installed controls, trigger/harness, plumbing, connector and complete current package with Spectra. This historical Farallon or plug code is not assumed a universal alias; confirm exact scope and whether an adapter is included. Pre-Mk II-Z guidance requires actual harness identification, not age alone.
Automated MPC Z-Ion retrofit candidate only after confirming no generator is fitted and an approved 12/24V DC accessory supply is available. Do not connect Z-Ion directly to AC or 48V. Confirm installed controls, trigger/harness, plumbing, connector and complete current package with Spectra. This historical Farallon or plug code is not assumed a universal alias; confirm exact scope and whether an adapter is included. Pre-Mk II-Z guidance requires actual harness identification, not age alone.
Existing fitment requirements
KEEP THE ORIGINAL AND CURRENT REFERENCES TOGETHER
